Dragino LHT65N-VIB LoRaWAN Vibration Sensor

https://www.aiotkart.com/web/image/product.template/17701/image_1920?unique=4caf355

Dragino LHT65N-VIB is a LoRaWAN® vibration sensor designed for wireless equipment condition monitoring, vibration detection and machine runtime tracking. It uses a 3-axis accelerometer to detect vibration status, shocks and acceleration across the X, Y and Z axes, enabling vibration alarms, runtime calculation, event counting and vibration-strength monitoring through an IoT platform. The LHT65N-VIB also integrates temperature and humidity sensing and supports LoRaWAN v1.0.3 Class A communication, remote parameter configuration through LoRaWAN downlinks and AT commands. Powered by a built-in 2400mAh non-rechargeable battery designed for multi-year operation, it is suitable for industrial equipment, machinery, asset-condition and remote vibration monitoring applications in India, with an IN865 frequency variant available.

₹ 6,006.00 6006.0 INR ₹ 6,006.00

₹ 6,006.00

Not Available For Sale

(₹ 0.00 / UNIT)
8 people are viewing this right now

This combination does not exist.

Contact Us

  • LoRaWAN® v1.0.3 Class A compliant
  • 3-axis accelerometer (X, Y, Z) for vibration detection
  • Detect vibration alarm and shock events
  • Calculates device runtime and event counting
  • Built-in temperature and humidity sensor
  • Ultra-long range LoRa wireless communication
  • High interference immunity with low power consumption
  • Built-in 2400mAh non-rechargeable battery (3+ years typical use)
  • Remote configuration via LoRaWAN® downlink
  • Firmware upgradeable via program port
  • Compact design for easy installation

LoRaWAN® Specifications

  • Protocol: LoRaWAN® v1.0.3 Class A
  • Supported Bands: IN865
  • Compatible with standard LoRaWAN® gateways

Built-in Temperature Sensor

  • Resolution: 0.01°C
  • Accuracy: Typical ±0.3°C
  • Long Term Drift: < 0.02°C/year
  • Operating Range: -40°C to 85°C

Built-in Humidity Sensor

  • Resolution: 0.04 %RH
  • Accuracy: Typical ±3 %RH
  • Long Term Drift: < 0.25 %RH/year
  • Operating Range: 0 to 96 %RH

External Vibration Sensor

  • 3-axis accelerometer (X, Y, Z)
  • Detects vibration status, shock, and motion
  • Small form factor for flexible mounting

Battery

  • Type: Built-in non-rechargeable battery
  • Capacity: 2400mAh
  • Typical Life: More than 3 years (depending on transmission interval)

The Dragino LHT65N-VIB is widely used in India for:

  • Industrial automation and machine condition monitoring
  • Commercial infrastructure equipment health tracking
  • Water systems and pump vibration monitoring
  • Cold chain facility equipment status detection
  • Manufacturing line runtime and usage statistics
  • Utilities infrastructure monitoring
  • Infrastructure projects requiring vibration alarms
  • Campuses & institutions monitoring equipment usage and safety

Typical deployments include water leak detection, machine monitoring, wash basin usage counting, and pump performance monitoring.

You can purchase the genuine Dragino LHT65N-VIB from AIoTkart®, the Authorized Dragino Distributor in India, with PAN-India delivery and project-level support.

Yes. The LHT65N-VIB supports LoRaWAN® v1.0.3 Class A protocol and can operate with compatible LoRaWAN® gateways for long-range LPWAN deployments across industrial and commercial sites in India.

The sensor monitors vibration intensity, shock events, runtime, and counting data, along with built-in temperature and humidity measurements for complete environmental and equipment analysis.

Documents

LHT65N-VIB_User_Manual

Download

LHT65N-VIB_Datasheet

Download

LHT65N-VIB_Firmware

Download
