Dragino SE0X-LB LoRaWAN Soil Moisture & EC Sensor Transmitter

https://www.aiotkart.com/web/image/product.template/17769/image_1920?unique=77af473

Dragino SE0X-LB is a LoRaWAN® Soil Moisture & EC Sensor Transmitter designed for wireless soil-condition monitoring in agriculture and smart farming applications. It supports connection of up to four external soil probes with 3.5m probe cables to monitor soil moisture, soil temperature and electrical conductivity (EC). The system uses the FDR method for soil-moisture measurement with temperature and conductivity compensation and transmits collected data to a LoRaWAN IoT server. The SE0X-LB supports LoRaWAN 1.0.3 Class A communication, Bluetooth 5.1 configuration, LoRaWAN remote configuration and wireless OTA firmware updates. With an IP66 enclosure, 8500mAh Li-SOCl2 battery and IN865 frequency support, it is suitable for long-term agricultural soil monitoring deployments in India.

₹ 7,200.00 7200.0 INR ₹ 7,200.00

₹ 7,200.00

Not Available For Sale

(₹ 0.00 / UNIT)
10 people are viewing this right now

This combination does not exist.

Contact Us

  • LoRaWAN® 1.0.3 Class A compliant
  • Supports up to 4 external soil sensor probes (3.5m cable length)
  • Measures Soil Moisture (FDR method)
  • Measures Soil Temperature (RTD calibrated)
  • Measures Soil Conductivity (EC with temperature compensation)
  • Factory calibrated for mineral soil type
  • Ultra-low power consumption
  • Bluetooth v5.1 configuration support
  • Remote configuration via LoRaWAN® downlink
  • Wireless OTA firmware updates
  • AT command support
  • IP66 waterproof enclosure
  • Powered by 8500mAh Li/SOCl2 battery

Electrical Characteristics

  • Power Supply: Built-in 8500mAh Li/SOCl2 battery
  • Supply Voltage: 2.5V ~ 3.6V
  • Operating Temperature: -40°C to 85°C

Soil Moisture

  • Range: 0 – 100.00 V/V %
  • Resolution: 0.01 V/V %
  • Accuracy:
    • ±3% (0–53%) V/V %
    • ±5% (>53%) V/V %
  • Measurement Method: FDR with temperature & EC compensation

Soil Temperature

  • Range: -40.00°C ~ 85.00°C
  • Resolution: 0.01°C
  • Accuracy:
    • <0.3°C (-10°C ~ 50°C)
    • <0.6°C (other ranges)
  • Measurement Method: RTD, calibrated

Soil Conductivity (EC)

  • Range: 0 – 20000 µS/cm (25°C) (0–20.0 EC)
  • Resolution: 1 µS/cm
  • Accuracy: 2% FS
  • Measurement Method: Conductivity with temperature compensation

LoRa Specifications

  • Frequency Range: 862 ~ 1020 MHz
  • Max RF Output: +22 dBm
  • RX Sensitivity: Down to -139 dBm
  • Supported Bands: IN865

Power Consumption

  • Sleep Mode: 5µA @ 3.3V
  • LoRa Transmit Mode:
    • 125mA @ 20dBm
    • 82mA @ 14dBm

Physical Specifications

  • Enclosure Protection: IP66
  • Device Size: As per manufacturer specification
  • Device Weight: As per manufacturer specification

The SE0X-LB is suitable for:

  • Smart Agriculture
  • Precision Farming
  • Saline Soil Monitoring
  • Irrigation Control Systems
  • Crop Health Monitoring
  • Agricultural Research
  • Greenhouse Automation

SE0X-LB is calibrated for saline-alkali soil and loamy soil. If users want to use it for other soil, they can calibrate the value in the IoT platform base on the value measured by saline-alkali soil and loamy soil. The formula can be found at this link.

Documents

User Manual
Download

SE0X-LB_Datasheet

Download

SE0X-LB_Firmware

Download
