Dragino LCC01-LB LoRaWAN Load Cell Converter

https://www.aiotkart.com/web/image/product.template/17682/image_1920?unique=e8a3250

Dragino LCC01-LB is a LoRaWAN® Load Cell Converter designed to connect standard 4-wire load cells to long-range LoRaWAN networks for remote weight and load monitoring. It supports third-party load cells across measurement ranges from approximately 100 g up to 10 tonnes, making it suitable for industrial weighing, tank and silo monitoring, inventory measurement and other IoT weighing applications. The LCC01-LB supports LoRaWAN 1.0.3 Class A communication, Bluetooth configuration, LoRaWAN remote configuration and wireless OTA firmware updates. With ultra-low-power operation, an 8500mAh Li-SOCl2 battery and an IN865 frequency option, it is well suited for wireless load-cell monitoring deployments in India.

₹ 11,756.00 11756.0 INR ₹ 11,756.00

₹ 11,756.00

Not Available For Sale

(₹ 0.00 / UNIT)
10 people are viewing this right now

This combination does not exist.

Contact Us

  • LoRaWAN® 1.0.3 Class A compliant
  • LoRa frequency bands including IN865 for India
  • Standard 4-wire interface for third-party load cells
  • Weight measurement range from 100g to 10 tons (based on load cell)
  • Ultra-low power consumption design
  • Periodic uplink with configurable downlink control
  • BLE configuration support
  • Remote configuration via LoRaWAN®
  • Wireless OTA firmware updates
  • 8500mAh Li/SOCl2 battery for up to 5 years operation
  • Pre-loaded unique LoRaWAN® keys for easy activation

Common DC Characteristics

  • Supply Voltage: Built-in battery, 2.5V ~ 3.6V
  • Operating Temperature: -40°C to 85°C

LoRa Specifications

  • Frequency Range (HF): 862 ~ 1020 MHz
  • Supported Bands:  IN865
  • Max RF Output: +22 dBm
  • RX Sensitivity: Down to -139 dBm
  • High blocking immunity and interference resistance

Battery

  • Type: Li/SOCl2 non-rechargeable battery
  • Capacity: 8500mAh
  • Self-Discharge: <1% per year @ 25°C
  • Max Continuous Current: 130mA
  • Max Boost Current: 2A (1 second)

Power Consumption

  • Sleep Mode: 5uA @ 3.3V
  • LoRa Transmit Mode: 125mA @ 20dBm, 82mA @ 14dBm

Interfaces & Compatibility

  • Interface: Standard 4-wire load cell input
  • Load Cell Types Supported: Bending beam, compression, canister, S-type and other standard load cells

The Dragino LCC01-LB is ideal for IoT-based weight monitoring across India in:

  • Industrial automation and manufacturing weighing systems
  • Commercial infrastructure such as supermarkets and retail scales
  • Water systems and tank/silo weighing
  • Cold chain logistics and warehouse weight monitoring
  • Truck scales and weighbridges
  • Railroad scales and crane scales
  • Hopper weighing and packaging machines
  • Campuses & institutions conducting testing and measurement applications

You can purchase the genuine Dragino LCC01-LB from AIoTkart®, the Authorized Dragino Distributor in India, with PAN-India delivery and project-level technical support.

Yes. The LCC01-LB supports LoRaWAN® 1.0.3 Class A and IN865 band, making it suitable for long-range LPWAN weight monitoring systems across industrial and commercial sites in India.

The LCC01-LB supports standard 4-wire load cells including bending beam, compression, canister, S-type load cells, weighbridges, hopper systems, and truck scales.
