Dragino PS-LB-NA M12 LoRaWAN Analog Sensor Interface

https://www.aiotkart.com/web/image/product.template/17739/image_1920?unique=dc372da

Dragino PS-LB-NA M12 is a battery-powered LoRaWAN® analog sensor interface designed to connect conventional analog sensors to long-range IoT networks. It provides one 0–20mA current input and one 0–30V voltage input, together with controllable 5V and 12V outputs for powering compatible external sensors. The PS-LB-NA converts analog measurements into LoRaWAN data for transmission to an IoT platform and supports LoRaWAN 1.0.3 Class A communication, periodic uplinks, Bluetooth 5.1 configuration, LoRaWAN remote configuration and wireless OTA firmware updates. This variant uses an M12 cable entry and is powered by an 8500mAh Li-SOCl2 battery. With IN865 frequency support, it is suitable for industrial instrumentation, pressure, level, flow and other analog sensor monitoring applications in India.

₹ 6,645.00 6645.0 INR ₹ 6,645.00

₹ 6,645.00

Not Available For Sale

(₹ 0.00 / UNIT)
7 people are viewing this right now

This combination does not exist.

Contact Us

  • LoRaWAN® 1.0.3 Class A compliant
  • 1 × 0~20mA analog current input
  • 1 × 0~30V analog voltage input
  • 5V and 12V output to power external sensors
  • Converts analog values to LoRaWAN® data
  • Ultra-low power consumption design
  • Monitor battery level remotely
  • BLE v5.1 configuration support
  • Remote configuration via LoRaWAN® downlink
  • Wireless OTA firmware update support
  • Periodic uplink with configurable interval
  • Band support IN865 (India)
  • 8500mAh Li/SOCl2 battery (PS-LB-NA)

Micro Controller

  • MCU: 48MHz ARM
  • Flash: 256KB
  • RAM: 64KB

Power Supply

  • Supply Voltage: 2.5V ~ 3.6V
  • Operating Temperature: -40°C to 85°C

Analog Input Specifications

Current Input (DC):

  • Range: 0 ~ 20mA
  • Accuracy: 0.02mA
  • Resolution: 0.001mA

Voltage Input:

  • Range: 0 ~ 30V
  • Accuracy: 0.02V
  • Resolution: 0.001V

LoRa Specifications

  • Frequency Range (Band 1 HF): 862 ~ 1020 MHz
  • Max RF Output: +22 dBm
  • RX Sensitivity: Down to -139 dBm
  • Excellent blocking immunity
  • Bands: IN865

Battery Specifications (PS-LB-NA)

  • Type: Li/SOCl2 (Non-rechargeable)
  • Capacity: 8500mAh
  • Self-Discharge: <1% per year @ 25°C
  • Max Continuous Current: 130mA
  • Max Boost Current: 2A (1 second)

Power Consumption

  • Sleep Mode: 5µA @ 3.3V
  • LoRa Transmit Mode: 125mA @ 20dBm
  • 82mA @ 14dBm

Package Includes

  • 1 × PS-LB-NA LoRaWAN® Analog Sensor

The Dragino PS-LB-NA-M12 LoRaWAN® Analog Sensor is ideal for:

  • Industrial automation signal monitoring
  • Commercial infrastructure equipment monitoring
  • Water system pressure and level transmitters
  • Cold chain temperature or pressure transmitters
  • Manufacturing process monitoring
  • Utility SCADA signal integration
  • Infrastructure monitoring projects
  • Campuses and institutional facilities

It enables integration of standard 4–20mA and 0–30V industrial sensors into LoRaWAN®-based Industrial IoT networks across India.

You can purchase the Dragino PS-LB-NA-M12 LoRaWAN® Analog Sensor from AIoTkart®, the Authorized Dragino Distributor in India, with nationwide delivery and industrial project support.

Yes, the device supports 0–20mA current input and 0–30V voltage input, making it suitable for integrating industrial transmitters such as pressure, level, and flow sensors into LoRaWAN® networks.

Yes, with ultra-low power consumption, 8500mAh battery (LB version) or solar option (LS version), and IN865 band support, it is suitable for long-term Industrial LoRaWAN® deployments in India.
